ZMPT101B AC Voltage Transformer Sensor PCB Mount
In stock
Order before 12.00PM
The ZMPT101K is a high-accuracy, ultra-miniature voltage transformer designed for precise AC voltage and phase measurement in UPS systems, energy meters, and power monitoring circuits. With a 1:1 turn ratio, 2mA input/output, and UL certification, this transformer offers exceptional stability, linearity, and isolation in a compact PCB-mountable package.
Unlike the ZMPT101B, the ZMPT101K carries UL certification, making it ideal for safety-critical power monitoring applications. Its epoxy-encapsulated body ensures long-term reliability, even under harsh environmental conditions
Features:
-
UL Certified version of ZMPT101B
-
Miniature size with high accuracy (class 0.2)
-
1:1 precision turn ratio (1000:1000)
-
Ideal for UPS, power meters, inverters, and AC monitoring systems
-
High isolation voltage: 4000V
-
Excellent phase angle stability and low linearity error ≤0.2%
-
PCB mountable for compact designs
Specifications:
-
Primary Rated Current: 2 mA
-
Primary Max Current: 8 mA
-
Secondary Current: 2 mA
-
Load Resistance Range: 0–400 Ω
-
Accuracy Class: 0.2
-
Isolation Voltage: 4000V
-
Operating Temperature: -40 °C to +85 °C
-
Model: ZMPT101K
-
Turn Ratio: 1000:1000
-
Linear Measurement Range: 0–1000V (with 100 Ω sampling resistor)
-
Phase Angle Error: ≤20′ (at 2 mA input)
-
Permissible Error: –0.3% to +0.2%
-
Encapsulation: Epoxy Resin
-
Mounting: PCB (Pin length >3mm)
Applications:
- UPS Voltage Sensing
- AC Phase Measurement
- Smart Energy Meters
- Power Monitoring Systems
- Voltage Feedback Circuits
