UNI-T UT33B+ digital pocket multimeter auto range 600V (CAT ll 600V) 10A AC DC Voltage Current Resistance +2mF Capacitance Tester Backlight Display.
UNI-T UT33B+ is a reliable and precise pocket digital multimeter with a durable protective case and a large LCD. The device measures AC/DC voltage, AC/DC current, resistance and capacitance, and is used for diode check and continuity test.
Features:
Specifications:
| Manufacturer | UNI-T |
| Model | UT33B+ |
| DC voltage | 200 mV / 2000 mV / 20 V / 200 V / 600 V ±(0.7%+3) |
| AC voltage | 200 V / 600 V ±(1.2%+3) |
| DC current intensity | 200 µA / 200 mA / 10 A ±(1%+2) |
| AC current intensity | No |
| Resistance | 200 Ohm / 2000 Ohm / 20 kOhm / 200 kOhm / 20 MOhm ±(0.8%+2) |
| Capacity |
No |
| Maximum voltage | 600 V |
| Humidity | ≤ 75% RH |
| Socket 10 A | 10 A 250 V 5 x 20 mm fuse |
| MA/uA socket | Fuse 200 mA 250 V 5 x 20 mm |
| Maximum value | 2000, above on OL display, refresh 2-3x/min |
| Polarisation | symbol - displays during minus polarity |
| Inductivity | No |
| Operating temperature | 0°C to 40°C (for more accurate measurement, use the device at 18°C to 28°C) |
| Storage temperature | from -10°C to +50°C |
| Automatic range selection | No |
| Standby | Yes |
| Beacon | Yes |
| Transistor tester | not |
| Diode tester | Yes |
| Battery tester | Yes |
| Data Hold function | Yes |
| Relative measurement | No |
| Data transmission function | No |
| Battery indicator | Yes |
| Backlighting | Yes |
| Display | LCD, illuminated, 55 x 23 mm |
| Dimensions | 134 x 77 x 47 mm |
| Power supply | 2 x1.5 V AAA battery (LR03) |
| Mass | 205 g |
