The UTP3315TFL-II Linear DC Power Supply is a high-quality, stable device designed to deliver pure and reliable signals. It is a versatile tool, ideal for use in university labs, technical trade schools, electronics production lines, and household appliance repair companies. With advanced features like short-circuit protection, overload protection, and reverse polarity protection, it ensures safety and reliability in operation.

Features:

• Precise Output: High-precision 4-digit voltage and current LED display for accurate monitoring.
• Protection Features: Short-circuit, overload, and reverse polarity protection to safeguard your devices.
• Low Ripple & Noise: Ensures a clean and stable output for sensitive electronics.
• User-Friendly Design: Lightweight build with a concise and intuitive interface.
• Auto Conversion: Seamless switching between constant voltage (CV) and constant current (CC) modes with current limit protection.

Specifications:

Operating Conditions

• Operating Voltage: AC 110V/220V ± 5%, 50Hz/60Hz
• Temperature:
  • Operating: 0°C ~ 40°C
  • Storage: -10°C ~ 80°C
• Humidity:
  • Operating: ≤ 85%
  • Storage: ≤ 80%

Electrical Parameters

• Output Voltage: 0–30 V
• Output Current: 0–5 A
• Maximum Output Power: 160 W
• Load Regulation:
  • Voltage: < 0
  • Current: < 0
• Line Regulation:
  • Voltage: < 0
  • Current: < 0
• Ripple & Noise:
  • Voltage: ≤ 2 mVrms
  • Current: ≤ 3 mArms

Measurement & Accuracy

• Setting Resolution (25°C ± 5°C):
  • Voltage: 10 mV
  • Current: 1 mA
• Setting Accuracy (20 Hz–20 MHz):
  • Voltage: < 0
  • Current: < 0

Display & Power

• Display: High-precision 4-digit LED display
• Power Supply: AC 110V/220V ± 5%

Applications:

The UTP3315TFL-II is the perfect tool for:

• Educational Institutions: Laboratory experiments and student projects.
• Electronics Manufacturing: Assembly and testing of electronic devices.
• Repair Shops: Troubleshooting and repairing household appliances.
