The JF-0530B DC 6V Pull Push Solenoid is a compact electromagnetic actuator designed for short-stroke mechanical movement, locking, releasing, switching and positioning applications. With a 6V DC operating voltage, 10mm stroke and 5N force, BDTronics offers this small solenoid for robotics, automation, DIY electronics and custom electromechanical projects.

When 6V DC power is applied to the coil, the electromagnetic mechanism moves the plunger to provide linear push or pull movement. Its compact design makes it useful for space-constrained mechanisms that require electrically controlled mechanical actuation.

Features:

• JF-0530B electromagnetic solenoid

• DC 6V operating voltage

• Pull and push type linear movement

• 10mm stroke

• 5N force

• Compact electromagnetic actuator

• Simple ON/OFF operation

• Suitable for mechanical locking and releasing

• Suitable for robotics and automation

• Useful for DIY electronics projects

• Suitable for switches, latches and small mechanisms

• Can be controlled using a relay, transistor or MOSFET driver

Specifications:

• Model: JF-0530B

• Product Type: Pull Push Type Solenoid

• Operating Voltage: DC 6V

• Stroke: 10mm

• Force: 5N

• Actuation: Electromagnetic linear movement

• Movement Type: Push / Pull

• Application: Locking, releasing, switching, positioning and automation

Applications:

The JF-0530B 6V solenoid is suitable for electronic locks, mechanical latches, automatic switches, robotics, vending mechanisms, dispensing mechanisms, small automation equipment, DIY machines, control mechanisms and custom electromechanical projects.

It can also be controlled by microcontrollers such as Arduino, ESP32 or STM32 through an appropriate transistor or MOSFET driver circuit.

Control:

Apply 6V DC to the solenoid coil to activate the electromagnetic actuator. For microcontroller or semiconductor switching, use a suitable MOSFET or transistor driver with an appropriate flyback diode across the coil.

Use a power supply and switching component capable of handling the solenoid's actual coil current.

Important Notes:

• Operate the solenoid at the specified 6V DC voltage.

• Do not apply excessive voltage to the coil.

• The specified 5N force depends on the plunger position and mechanical installation.

• Ensure the plunger can move freely without excessive mechanical resistance.

• For repeated or continuous operation, consider coil heating and the appropriate duty cycle.

• Use suitable electrical protection when switching the coil electronically.
