The Original Prusa XL is a professional large-format 3D printer engineered for high-performance multi-material printing with maximum precision. Featuring a lightning-fast tool changer system and up to five independent toolheads, this next-generation 3D printer supports advanced prototyping, low-volume manufacturing, and creative model making at an entirely new scale.

Proudly designed and assembled in the EU, the Prusa XL is a plug-and-play powerhouse built for precision, speed, and flexibility — perfect for engineers, educators, designers, and makers demanding industry-grade reliability and material versatility.

Features:

• Massive Build Volume: 360×360×360 mm (14.17"³) for large-scale projects

• 5 Independent Toolheads: Seamless multi-material and multi-color prints

• Advanced Toolchanger: Rapid switching for reduced print times

• Direct Drive Nextruder: Compatible with flexible filaments and precision detail

• Segmented Heated Bed: 16-zone heated bed for energy-efficient, localized heating

• Automatic Mesh Bed Leveling: Consistent first layer quality across the entire bed

• Prusa Connect & Wi-Fi: Remote printing and monitoring capabilities

• High-Temperature Support: Nozzle up to 290 °C, heatbed up to 115 °C

• Silent Operation: Quiet, stable, and designed for office or lab environments

Professional Use Cases:

• Engineering & Prototyping: High-accuracy parts, tight tolerances, and engineering-grade materials

• Medical Modeling: Flexible and rigid part printing for anatomical accuracy

• Educational Institutions: Multi-user environment support with modular toolheads

• Low-Volume Manufacturing: Affordable and efficient production-ready parts

Multi-Material Excellence:

Achieve clean, perfect surface finishes using support materials like PLA with PETG, or create durable, hybrid parts using PCCF exteriors with PETG infill. Upgradeability allows you to begin with a single toolhead and expand to a 5-toolhead setup, enabling complex models, soluble supports, and vibrant multi-color prints.

Enclosure Kit (Optional Add-On):

Maximize print quality with the Prusa XL Enclosure Kit. Ideal for ABS, ASA, PC, and other high-temp materials, the enclosure:

• Maintains stable temperature

• Filters ultra-fine particles

• Reduces noise

• Eliminates warping and drafts

Technical Specifications:

Build & Mechanical

• Build Volume: 360 × 360 × 360 mm (14.17" × 14.17" × 14.17")

• Layer Height: 0.05 – 0.30 mm

• Filament Diameter: 1.75 mm

• Printer Dimensions:

  • Width: 700 mm | Height: 900 mm | Depth: 720 mm

  • Weight: 27.9 kg (Single Tool) to 33.7 kg (Five-Tool)

Electronics & Control

• Mainboard: Custom 32-bit xBuddy with STM32 processor

• Stepper Drivers: Trinamic 2130

• Display: 3.5" full-color graphic LCD

• Connectivity: USB, LAN, Wi-Fi (via ESP module), Prusa Connect

Extruder & Drive

• Extruder: Direct Drive Nextruder, E3D V6 compatible

• Filament Path: All-metal hotend with aluminum heatsink

• Gear System: Planetary gearbox with 10:1 ratio

Temperature & Sensors

• Max Nozzle Temp: 290 °C (554 °F)

• Max Heatbed Temp: 115 °C (239 °F)

• Sensors: Filament sensor, Loadcell sensor, Power Panic, 4 Semitec thermistors, fan RPM monitoring

Print Surface

• Heated Bed: Segmented 16-zone bed with magnetic steel PEI sheets

• Calibration: Fully automatic mesh bed leveling

Material Compatibility

Supports a wide range of filaments:

• Standard: PLA, PETG, Flex, CPE, PVB, PVA

• Advanced (with enclosure): ASA, ABS, PC, PP, HIPS, PA

Power Requirements

• PSU: Custom 240W Delta power supply with Power Panic

• Power Consumption:

  • Standby: 80W

  • Heating: 550W

  • Printing: 235W

Included in the Box:

• Fully Assembled Prusa XL 5-Toolhead Printer

• Power Cable (UK)

• Enclosure Kit (if bundled)

• Printed Handbook (EN)

• Online Assembly & Setup Manual

• Sample Prints & Test Filaments
