The MT3608 AEROSEMI high efficiency 1.2MHz 2A step up converter is a reliable solution for battery-powered equipment, LCD bias supply, set-top boxes, DSL and cable modems, routers, and PCI or PCI Express powered networking cards. Designed for low power applications, this compact 6-pin SOT23-6 package module delivers up to 28V output voltage with adjustable settings, ensuring maximum efficiency and stable performance in a variety of electronic devices. Its integrated 80mΩ power MOSFET, internal 4A switch current limit, and automatic pulse frequency modulation at light loads provide excellent energy saving and extended battery life. Ideal for engineers, hobbyists, and electronics designers in Bangladesh looking for efficient, compact step-up converters.

Features:

• Integrated 80mΩ Power MOSFET
• 2V to 24V Input Voltage
• 1.2MHz Fixed Switching Frequency
• Internal 4A Switch Current Limit
• Adjustable Output Voltage
• Internal Compensation
• Up to 28V Output Voltage
• Automatic Pulse Frequency Modulation Mode at Light Loads
• Up to 97% Efficiency
• Available in a 6-Pin SOT23-6 Package

Specifications:

• Input Voltage: 2V to 24V
• Output Voltage: Up to 28V adjustable
• Switching Frequency: 1.2MHz
• Maximum Output Current: 2A
• Efficiency: Up to 97%
• Package: 6-Pin SOT23-6
• Protection: Under-voltage lockout, current limit, thermal overload
• Operating Mode: Constant frequency step-up with automatic PFModulation
