The Mercury Medallion Module is a compact tilt detection sensor designed to accurately detect changes in orientation and movement. Featuring a built-in mercury tilt switch, resistor, and indicator LED, this module provides a simple digital output signal whenever the sensor changes position. When the module is tilted, the internal mercury ball opens or closes the circuit, triggering the output and illuminating the onboard LED indicator.

This tilt sensor module is widely used in Arduino projects, ESP32 applications, Raspberry Pi systems, robotics, security devices, motion detection systems, automation equipment, and educational electronics projects. Its compact design, low power consumption, and easy interface make it an ideal solution for orientation sensing and tilt-triggered control applications.

Features:

• High-quality mercury tilt sensor module

• Accurate orientation and tilt detection

• Built-in mercury switch mechanism

• Integrated LED status indicator

• Fast and reliable switching response

• Digital signal output

• Compact and lightweight design

• Easy integration with Arduino and microcontrollers

• Stable operation with low power consumption

• Suitable for motion and position sensing

• Reliable switching performance

• Compatible with 3.3V and 5V systems

• Simple wiring and installation

• Ideal for educational and DIY projects

BDTronics supplies quality-tested Arduino modules, sensors, development boards, and electronics components for students, makers, engineers, and automation professionals. The Mercury Medallion Module is selected for dependable tilt sensing performance and easy integration into embedded electronics and automation projects.

Specifications:

• Model Type: Tilt Sensor Module

• Sensor Type: Mercury Tilt Switch

• Operating Voltage: 3.3V – 5.5V DC

• Output Type: Digital Signal

• Indicator LED: Yes

• Detection Method: Mercury Ball Contact Switching

• Response Type: Orientation-Based Trigger

• Interface: Digital Output

• Power Consumption: Low

• Compatibility: Arduino, ESP32, ESP8266, Raspberry Pi, STM32, AVR, PIC

How It Works:

• The module contains a mercury switch inside the sensor.

• When the module is tilted in a specific direction, the mercury ball completes the circuit.

• The output state changes and the onboard LED turns on.

• When returned to its original position, the circuit opens and the LED turns off.

• The digital output can be read directly by a microcontroller.

Pin Configuration:

• VCC: Power Supply (3.3V–5.5V)

• GND: Ground

• OUT: Digital Signal Output

How to Use:

• Connect VCC to a 3.3V or 5V power source

• Connect GND to system ground

• Connect OUT to a digital input pin of the microcontroller

• Upload a simple digital input reading program

• Monitor output changes as the sensor is tilted

• Use the output to trigger alarms, LEDs, relays, or automation actions

• Observe the onboard LED for quick status indication

Applications:

• Tilt detection systems

• Orientation sensing projects

• Motion-triggered devices

• Arduino automation projects

• Security alarm systems

• Anti-theft systems

• Robotics projects

• Position monitoring systems

• Smart home automation

• Industrial equipment monitoring

• Educational electronics experiments

• Vibration and movement detection

• Electronic toys and gadgets

• Embedded system development

• DIY electronics projects

Advantages:

• Simple digital interface

• Accurate tilt detection

• Compact design

• Low power consumption

• Built-in visual indicator

• Easy microcontroller integration

• Reliable operation

• Cost-effective sensor solution

Package Includes:

• 1 × Mercury Medallion Tilt Sensor Module
