Makerbase MKS 12864 V3.0 Smart LCD with SD Card Slot

In stock

MKS MINI 12864 V3.0 Smart LCD Display for MKS Tiny Bee, MKS Robin Nano V2/ V3, Sgen I V1/ V2, Gen I, Robin E3/ E3D motherboards.

It has RGB back light, supports chaning backlight color, Support Robin Nano V3, Sgen-I V1/V2, Gen-I. Both marlin 2.x and Klipper firmare are supported. The LCD Driver is based on ST7567. It supports both 3.3V and 5V logic input. Backlight mode is adjustable and enhanced with Neopixel RGB. There's SD Card slot in the back of the LCD panel. The LCD panel comes with cables and connectors. Caution: Please refer to the manual how to connect the LCD panel with different boards as in some boards EXP1 and EXP2 ports are located in opposite direction.


Special Price BDT 1,661.00 Regular Price BDT 1,860.00
  •  Cash on Delivery all over BD
  •  100% Authentic Product
  •  15 Days Easy Return
  •  Safe & Secure Payment

Technical Specifications:

  • LCD driver: ST7567
  • Logic level: Support 3.3V and 5V logic levels
  • Backlight mode: Neopixel RGB adjustable LED backlight
  • Backlight adjustment: Lights > Light Presets (Marlin)
  • Firmware support: Marlin 2.x, Klipper
  • Motherboard support: MKS Robin Nano V2/ V3, Sgen I V1/V2, Gen I, Robin E3/ E3D, MKS Tiny Bee

If you want to buy MKS Tiny Bee 32 bit controller board, please visit:
https://www.bdtronics.com/mks-tinybee-motherboard-32bit-3d-printer-control-board-esp32-mcu.html



Makerbase MKS 12864 V3.0 Smart LCD with SD slot wiring with MKS Boards

Makerbase MKS 12864 V3.0 Smart LCD with SD slot wiring with other boards

Makerbase MKS 12864 V3.0 Smart LCD with SD slot firmware setting

Makerbase MKS 12864 V3.0 Smart LCD with SD slot color setting page 1

Makerbase MKS 12864 V3.0 Smart LCD with SD slot color setting page 2

Makerbase MKS 12864 V3.0 Smart LCD with SD slot dimension
