This high-speed M.2 NVMe to PCIe 4.0 Adapter Card allows you to install an NVMe SSD on any desktop PC that does not have a built-in M.2 slot. Designed for full PCIe Gen4 bandwidth, it delivers ultra-fast 64Gbps transfer speed, stable data performance, and wide compatibility with popular NVMe SSD models. Ideal for upgrading older systems or expanding storage while maintaining maximum read/write performance.

Features:

• Adds M.2 NVMe storage to motherboards without M.2 slots using PCIe 4.0 channels.

• Supports PCIe 4.0 x4 bandwidth with speeds up to 64Gbps for maximum SSD performance.

• Achieves up to 5000+ MB/s random read and 4500+ MB/s write (max) based on SSD capability.

• Backward compatible with PCIe 1.0, 2.0, and 3.0 slots for wider motherboard support.

• Supports NVMe SSD size formats 2280, 2260, 2242, and 2230.

• Multi-layer PCBA design ensures stable and safe operation under heavy load.

• Built-in protections: overcurrent, overvoltage, short-circuit, EMI shielding, and overheating protection via heatsink layer.

• Compatible with Samsung, Intel, Plextor, Kingston and most major NVMe SSD brands.

• Plug-and-play for Windows 10/11 with native NVMe driver support.

• No additional power cable required; draws power directly from PCIe slot.

• Ideal for gaming PCs, workstation upgrades, and expanding SSD storage at high speed.

• Includes mounting screws and standoffs for easy installation.

Important Notes:

• Does not support SATA NGFF M.2 SSDs (NVMe only).

• Windows 7 does not natively recognize NVMe SSDs. Additional NVMe drivers and BIOS support are required for installation and booting.

• Some older BIOS versions may not offer PCIe drive boot options; this is not an adapter issue.

How to Use:

• Power off the PC and unplug all power cables.

• Insert the adapter card into an available PCIe 4.0/3.0/2.0/1.0 slot (x4 recommended, but compatible with x1/x4/x8/x16).

• Install the NVMe SSD on the adapter using the provided screw and standoff.

• Ensure proper seating and tighten the screw to secure the SSD.

• Boot into Windows 10/11 to automatically detect the NVMe SSD.

• Initialize and format the SSD in Disk Management before use.

Installation Tips:

• Use a PCIe 4.0 slot for full 64Gbps speed.

• Ensure proper airflow for optimal SSD temperature control.

• For Windows 7 users, integrate NVMe drivers into installation media before setup.

• Check BIOS settings for NVMe support when attempting to boot from the SSD.

Specifications:

• Interface: PCIe 4.0 x4 (compatible with x1/x4/x8/x16 slots)

• Supported SSD Type: M-Key NVMe (Not compatible with SATA NGFF)

• Max Speed: Up to 64Gbps

• Supported NVMe Sizes: 2230 / 2242 / 2260 / 2280

• Material: Multi-layer PCBA with heat dissipation layer

• Protections: Overcurrent, Overvoltage, Short Circuit, EMI Shielding, Overheat Control

• Supported OS: Windows 10/11 Plug-and-Play, Windows 7 (requires NVMe driver)

• Compatible SSD Brands: Samsung, Intel, Plextor, Kingston, WD, Corsair, and more
