Specifications:

Technical Specifications

• Product Category: Operational Amplifiers - Op Amps
• Mounting Style: Through Hole
• Package / Case: PDIP-14
• Number of Channels: 4 Channel
• Supply Voltage - Max: 32 V, +/- 16 V
• GBP - Gain Bandwidth Product: 2.5 MHz
• Output Current per Channel: -
• SR - Slew Rate: 20 V/us
• Vos - Input Offset Voltage: -
• Supply Voltage - Min: 4.5 V, +/- 2.2 V
• Minimum Operating Temperature: 0 C
• Maximum Operating Temperature: + 70 C
• Ib - Input Bias Current: 200 nA
• Operating Supply Current: 1.55 mA
• Shutdown: No Shutdown
• CMRR - Common Mode Rejection Ratio: -
• en - Input Voltage Noise Density: -
• Packaging: Tube
• Amplifier Type: General Purpose Amplifier
• Dual Supply Voltage: +/- 3 V, +/- 5 V, +/- 9 V
• Height: 4.57 mm
• Length: 19.3 mm
• Maximum Dual Supply Voltage: +/- 16 V
• Minimum Dual Supply Voltage: +/- 2.2 V
• Operating Supply Voltage: 4.5 V to 32 V, +/- 2.2 V to +/- 16 V
• Pd - Power Dissipation: 1150 mW
• Product: Operational Amplifiers
• Product Type: Op Amps - Operational Amplifiers
• Subcategory: Amplifier ICs
• Supply Type: Single, Dual
• Technology: Bipolar
• Voltage Gain dB: 68.94 dB
• Width: 6.35 mm
• Unit Weight: 0.032734 oz
