LDROBOT STL-06P LiDAR is a high-performance 360° laser scanner designed for robotics, AGV, AMR, mapping, obstacle avoidance, and SLAM applications. Engineered as a direct LD06 replacement, this upgraded LiDAR sensor delivers enhanced outdoor performance with 60Klx light resistance, 5000Hz ranging frequency, and up to 12 meters detection range. BDTronics supplies original LDROBOT STL-06P LiDAR in Bangladesh for robotics research, automation, and industrial navigation systems.

With ROS1 and ROS2 compatibility, this LiDAR module integrates seamlessly into robotic platforms using SLAM algorithms, autonomous navigation stacks, and real-time mapping systems.

Features:

• Direct LD06 replacement with upgraded performance

• 360° full-angle laser scanning

• 12m maximum detection range

• 5000Hz high-frequency ranging for fast data acquisition

• Outdoor light resistance up to 60Klx

• ROS1 and ROS2 supported

• High stability and fast refresh rate

• IP5X dust-resistant design

• Low acoustic noise operation

• Compact and lightweight for mobile robots

• Supplied by BDTronics Bangladesh

Performance Highlights:

• Ranging Frequency: 5000Hz fixed frequency

• Angular Resolution: Typical 0.72° @ 10Hz

• Pitch Angle Error: ±2°

• Yaw Angle Error: -1° to 1°

• Anti-background light resistance: Up to 60Klx

• Detection Range: Up to 12 meters

• Acoustic Noise: ≤45dB

• Designed for horizontal forward installation

How to Use:

• Mount LiDAR sensor horizontally on robot chassis

• Connect to controller via supported communication interface

• Integrate with ROS1 or ROS2 drivers

• Configure SLAM package for mapping and localization

• Adjust scanning frequency based on robot speed

• Use for obstacle detection, environment mapping, and path planning

Installation Instructions:

• Ensure stable mounting to avoid vibration

• Avoid covering optical window

• Operate within recommended temperature range

• Keep sensor free from excessive dust and moisture

• Use regulated power supply for stable performance

Applications:

• Autonomous mobile robots (AMR)

• Automated guided vehicles (AGV)

• SLAM mapping systems

• Obstacle avoidance systems

• Indoor and outdoor robotics navigation

• Warehouse automation

• Robotics research and development

• Smart inspection robots

Specifications:

• Model: STL-06P

• Brand: LDROBOT

• Scanning Angle: 360°

• Maximum Range: 12m

• Ranging Frequency: 5000Hz

• Angular Resolution: 0.72° @ 10Hz

• Light Resistance: 60Klx

• Acoustic Noise: ≤45dB

• Machine Life: 10,000 hours

• Working Temperature: -10°C to 45°C

• Storage Temperature: -30°C to 70°C

• Dust Protection: IP5X

• ROS Compatibility: ROS1, ROS2




Resrouces:

• Download Datasheet
