LCR-T7 Multi-functional Transistor MOSFET Diode Component Tester LCR Meter IR Decoder
In stock
Order before 12.00PM
This transistor detector is a cost-effective, versatile tool commonly used for testing a wide range of electronic components. It can detect NPN and PNP transistors, capacitors, resistors, diodes, triodes, MOSFETs (both N-channel and P-channel), IGBTs, JFETs, triacs, and batteries. Additionally, it is capable of detecting zener diodes and features a self-calibration function. The device also has the unique ability to decode infrared signals from remote controls—when the "IR" light on the remote is activated and a button is pressed, the detector will display the corresponding data code and infrared waveform. The one-button operation makes it easy to use, automatically detecting and shutting down after use, while the multi-functional button allows you to manually turn off the detector. Simply insert the component pins into the designated area, rotate the handle, and the detector will automatically perform the test. The results are displayed clearly on a color TFT screen, providing a significant advantage over traditional black-and-white displays.
Specifications:
- Material: ABS
- Power Mode: Rechargeable Lithium Battery
- Display: 160 x 128 TFT Screen
- Diode Range: Forward voltage < 4.50V
- Zener Diode Test Area: 0.01-20V
- Transistor Test Area: 0.01-4.5V
- Triac Range: Gate trigger current < 6mA
- Capacitance: 25pF - 100mF
- Resistor Range: 0.01 - 50MΩ
- Inductor Range: 0.01mH - 20H
- Battery Test Range: 0.1 - 4.5V
- Item Size: 9 * 7 * 2.7mm / 3.5 * 2.8 * 1.1in
- Item Weight: 84g / 2.9oz
- Package Size: 19 * 10 * 3cm / 7.5 * 3.9 * 1.2in
- Package Weight: 132g / 4.7oz
Note:
- Discharge electronic components before testing to protect the detector.
- Charge the device when the voltage and internal battery drop below 3V.
- Use a 5V battery or USB interface to charge.
Package List:
- 1 * Transistor Tester
- 1 * Electronic Component Set
- 1 * Cable
- 3 * Test Hooks
