IR21531PBF Gate Drivers HALF BRDG DRVR 600V 15.6Vclamp 0.6 DIP 8

IR21531PBF Gate Drivers HALF BRDG DRVR 600V 15.6Vclamp 0.6

In stock

SKU PRD-00002416
Category: ICs
Delivery Info
truck-fast
Inside Dhaka: 1-2 days
Express (Dhaka): 24 hours
Order before 12.00PM
Outside Dhaka: 2-3 days
hand-holding-dollar
Cash on delivery all over BD
Quality
award
100% authentic product
circle-check
Quality product guaranteed
Service
repeat
7 days easy return
credit-card
Safe & secure payment
Write Your Own Review
Only registered users can write reviews. Please Sign in or create an account

Product Details

Specifications:

      Technical Specifications

    • Product Category: Gate Drivers
    • Product: Half-Bridge Drivers
    • Type: High-Side, Low-Side
    • Mounting Style: Through Hole
    • Package / Case: DIP-8
    • Number of Drivers: 2 Driver
    • Number of Outputs: 2 Output
    • Output Current: 260 mA
    • Supply Voltage - Min: 10 V
    • Supply Voltage - Max: 20 V
    • Rise Time: 150 ns
    • Fall Time: 100 ns
    • Minimum Operating Temperature: - 40 C
    • Maximum Operating Temperature: + 125 C
    • Packaging: Tube
    • Features: Synchronous
    • Height: 5.33 mm
    • Length: 10.92 mm
    • Logic Type: CMOS
    • Operating Supply Current: 5 mA
    • Output Voltage: 10 V to 20 V
    • Pd - Power Dissipation: 1000 mW
    • Product Type: Gate Drivers
    • Subcategory: PMIC - Power Management ICs
    • Technology: Si
    • Width: 7.11 mm
    • Part # Aliases: IR21531PBF SP001544046
    • Unit Weight: 0.080001 oz
