The Handheld Fiber Laser Engraving Machine is a compact, portable, and high-precision laser marking solution designed for industrial, workshop, and on-site marking applications. Built with advanced German design concepts and high-quality components, this handheld laser engraver delivers stable performance, long service life, and excellent marking quality on a wide range of materials. Using fiber laser technology with a wavelength of 1064nm, it supports fast, permanent, and high-contrast engraving without consumables. The integrated all-in-one design with an 8-inch touch control screen, Linux-based system, and optional built-in battery makes it ideal for mobile marking, production lines, maintenance work, and customized marking needs.

Features:

• Handheld fiber laser engraving and marking machine

• Available power options: 30W fiber laser

• All-aluminum body with sandblasted anodized finish

• Compact, lightweight, and ergonomic handheld design

• Integrated system with 8-inch HD color touch screen

• Linux-based control system with built-in wizard interface

• High-speed marking with low noise and stable output

• Red light positioning for accurate alignment

• Air-cooled system, no water chiller required

• Optional built-in 24V lithium battery for portable use

• Supports handheld, desktop, and mobile workstation configurations

Specifications:

• Laser Type: Fiber Laser

• Laser Wavelength: 1064nm

• Laser Power Options: 30W

• Actual Output Power: ≥30W

• Marking Speed: ≤12000 mm/s

• Minimum Line Width: 0.0012 mm

• Marking Mode: Static, analog, encoder

• Production Line Speed: 0–130 m/min (material dependent)

• Positioning Method: Red light indication

• Cooling System: Air cooling

• Power Supply: 220V / 50Hz (external adapter)

• Power Consumption: 200W

System & Software

• Operating System: BslApp (Linux-based)

• Control Interface: 8-inch built-in touch controller

• Language Support: English, Chinese, French, German, Spanish, Russian, Arabic

• User Management: Multi-user permission control

• Data Protection: Power-off data protection

• Printing Signals: Start, status, completion, fault alarm

• File Formats Supported: BMP, DXF, HPGL, JPEG, PLT

• Barcode Types: Code39, Code128, Code126, QR code, custom codes

• Fonts Supported: Chinese, English, numeric, standard industrial fonts

Battery & Portability

• Optional Built-in Battery: 24V lithium, 12Ah

• Battery Endurance: 12–16 hours normal use

• Supports use while charging

• Total Machine Weight: Approx. 8.25kg

• Handheld Marking Head Weight: Approx. 1.25kg

Dimensions & Weight

• Main Unit Size: 270 × 155 × 245 mm

• Handheld Head Size: 240 × 100 × 230 mm

• Packing Carton Size: 470 × 410 × 360 mm

• Cable Length: 1.4 meters

Environmental Requirements

• Operating Temperature: 0°C – 45°C

• Operating Humidity: ≤95%, non-condensing

• Storage Temperature: -20°C – 60°C

• Storage Humidity: 10% – 90%

• Environment: No vibration, indoor use

Applications

• Metal engraving and marking

• Stainless steel, aluminum, brass, copper marking

• Tools, molds, parts identification

• Serial numbers, QR codes, barcodes

• Industrial nameplates and tags

• Pipe and cylindrical surface marking

• Automotive, electronics, hardware industries

• On-site maintenance and mobile engraving tasks

How to Use

• Power on the device using the touchscreen interface

• Select marking file or input text, barcode, or QR code

• Align marking area using red light positioning

• Adjust power, speed, and frequency settings

• Hold the marking head steadily over the workpiece

• Start marking via touchscreen or trigger input

Product Instructions

• Wear appropriate laser safety eyewear during operation

• Do not expose skin or eyes to direct or reflected laser radiation

• Use only in controlled environments

• Ensure proper grounding and power connection

• Clean lens and marking head periodically

• This is a Class 4 laser product—professional use recommended

Package Includes

• Handheld Fiber Laser Engraving Machine × 1

• Power Cable × 1

• User Manual × 1

• Warranty Card × 1

• Certificate × 1

• USB Drive (software & data) × 1

• Debugging Tools & Accessories
