FNIRSI 1013D Plus Digital Oscilloscope 100Mhz DSO 2 Channels with 7 inch Touch LCD Screen
4.85
10
In stock
2 Channels, 100MHz bandwidth each
1GSa/s Sampling Rate
7" TFT LCD Touch Screen
Voltage Range: 0-40V (1X), 0-400V (10X), 0-4000V (100X)
Trigger Modes: Single, Normal, Automatic
FFT Viewing and Lissajous Graphic Display
6000mAh Battery, 4 hours continuous usage
USB Picture Export and One-key Screenshot
. ...See more
SKU
BTS-00004670
...
BDT 20,680.00
BDT 29,370.00
Delivery Info
Inside Dhaka: 1-2 days
Express (Dhaka): 24 hours
Order before 12.00PM
Order before 12.00PM
Outside Dhaka: 2-3 days
Cash on delivery all over BD
Quality
100% Authentic Product
Quality Product Guaranteed
Service
Safe & secure payment
30 Days Warranty
Customer Support
The FNIRSI-1013D is a dual-channel oscilloscope designed for R&D and maintenance, offering a 1GSa/s real-time sampling rate and 100MHz bandwidth per channel. It supports various trigger modes (single/normal/auto) and can handle up to 400V with built-in high-voltage protection. The 7-inch 800x480 touchscreen provides easy control with one-key AUTO function for quick waveform display.
It includes convenient features like cursor measurements, peak detection, and built-in 1GB storage for up to 1000 screenshots and waveforms. The oscilloscope also supports USB connectivity for data sharing, and its 6000mAh battery lasts up to 4 hours on a single charge, usable even while charging.
Highlights:
- Professional Designed: FNIRSI oscilloscope has a real-time sampling rate of up to 1GSA/S and an analog bandwidth of 100MHZ * 2. Fnirsi oscilloscope has a complete trigger function (single/normal/automatic), it can be used freely for both periodic analog signals and aperiodic digital signals.
- Highly Performance: 7 inches, 800 * 480 resolution, bright colors and high contrast. Ultra-thin and easy to carry. Built-in high-voltage protection module,can tolerate a continuous voltage of up to 400V. 6000mAh high-performance lithium battery, can be used continuously for 4 hours after fully charged.
- Easy to Operate: Equipped with efficient one-button automatic device. One-click waveform saving and screenshots. The built-in 1GB storage space can store up to 1000 screenshots 1000 sets of waveform data.Powerful waveform picture manager supports thumbnail browsing, viewing, detailed viewing, page turning, deletion and waveform zooming in, zooming out, moving, etc
- Easily Measuring : Capacitive screen touch & gesture operation, cursor measurement function, when manually reading amplitude-frequency parameters, you do not need to read the background scale unit and quantity, and you can directly get the peak-to-peak value and frequency without conversion.
- Lissajous Graphic Display & FFT Viewing: Lissajous graphic display function can be used to compare the amplitude, frequency and phase of the two sets of signals. FFT viewing function can roughly estimation of the harmonic content of the signal.
Features
- 2 Channels
- Portable Handheld Tablet Oscilloscope
- 1GSa/s Sampling Rate (1X=5MHz,10X=100MHz)
- 100MHZ * 2analog bandwidth
- 7" TFT LCD Touch Screen
- Complete trigger function (single/normal/automatic).
- One-button AUTO and adaptive trigger (25%, 50%, 75%).
- Versatile usage for both periodic analog and aperiodic digital signals.
- high-voltage protection module.
- 1X can measure 0~40V, 10X can measure 0~400V,100X can measure 0~4000V
- Powerful Waveform Picture Manager.
- One-key Screenshot and Saving.
- Cursor measurement function.
- Powerful Waveform Picture Manager.
- Lissajous Graphic Display & FFT Viewing.
- USB Picture Export
- Ideal for both periodic analog and aperiodic digital signals.
- 6000mah battery, continuous usage for 4 hours
- Targeting the maintenance industry and the research and development industry.
Specifications:
| Brand | FNIRSI |
| Model | 1013D |
| Channels | 2 |
| Display | 7 inch 800*480 Pixels |
| Bandwidth | 100MHz |
| Sampling Rate | 1GSa/s |
| Rise Time | <3nS |
| Storage Depth | 240 Kbit |
| Timebase | 50S~10ns |
| Vertical Sensitivity | 50mV-500V |
| Input Resistance | 1MΩ |
| Trigger Mode | Single / Normal / Auto |
| Trigger Edge | Rising / Falling |
| Coupling | AC/DC |
| Highest Test Voltage | 1X:40V 10X:400V |
| Cursor | Position XY / Trigger Y |
| Roll Mode | Support |
| One-Button AUTO | Support |
| Waveform Manager | Support (1000 Pic + 1000 Waveform) |
| Voltage Accuracy | ±2% |
| Frequency Precision | ±0.01% High Precision |
| Parameter | 12 Kinds in Total |
| Power Supply | 6000mah Lithium Battery |
| Standby | 4 Hours |
| Extension | USB Export |
| Charging | Type-C 5V 2A/3A/4A |
See More
View all reviews above by our customers.
Customer Reviews
Price
5
Quality
5
Value
5
Imran's review
Review by
Imran
first e ektu complicated mone holo, but after using it's very easy. touch screen gesture ta valo kaj kore. 5 star from me.
Price
4
Quality
5
Value
4
Tanvir Rahman's review
Review by
Tanvir Rahman
পণ্যটি ভালো কিন্তু দামটা একটু বেশি মনে হয়েছে। তবে টাচ স্ক্রিনের সুবিধা এবং ব্যাটারি লাইফ অনেক ভালো। গুণমান নিয়ে কোনো অভিযোগ নেই।
Price
5
Quality
5
Value
5
Samiul Islam's review
Review by
Samiul Islam
product ta darun. touch screen onek smooth, battery backup o valo. auto button diye waveform instantly dekha jay. sobar jonno recommend korbo.
Price
5
Quality
5
Value
5
Nabil's review
Review by
Nabil
I was a bit skeptical at first, but this device exceeded expectations. The one-button auto feature is a lifesaver. Very intuitive interface. Great value for money.
Price
5
Quality
5
Value
5
Fahim Mahmud's review
Review by
Fahim Mahmud
Excellent oscilloscope for the price! The touchscreen is responsive and the 100MHz bandwidth handles all my hobby projects. Battery lasts about 4 hours as advertised. Highly recommended.
Price
5
Quality
4
Value
5
Shoeb Hasan's review
Review by
Shoeb Hasan
Good build quality and accurate measurements. The 7-inch screen is clear and bright. Only wish the memory depth was deeper, but overall a solid tool for field work.
Price
5
Quality
5
Value
5
Sajid's review
Review by
Sajid
প্রফেশনাল কাজের জন্য পারফেক্ট। ১০০MHz ব্যান্ডউইথ এবং ট্রিগার অপশনগুলো অসাধারণ। স্টোরেজ ফিচার খুব কাজে লাগে। সবার জন্য রেকমেন্ড করব।
Price
5
Quality
5
Value
5
Arif Hossain's review
Review by
Arif Hossain
দারুণ একটি অসিলোস্কোপ। টাচ স্ক্রিন খুবই স্মুথ এবং ব্যান্ডউইথও চমৎকার। ব্যাটারি ব্যাকআপ ভালো, তবে একটু ভারী মনে হলো। দাম অনুযায়ী মান ভালো।
Price
5
Quality
5
Value
5
Zobayer Ahmed's review
Review by
Zobayer Ahmed
amader lab e use kortesi, performance khub valo. 2 channel and 100MHz bandwidth enough for most testing. storage feature ta khub upokari. onek valo product.
Price
4
Quality
5
Value
5
Rafi's review
Review by
Rafi
dam ektu beshi holeo quality ta osadharon. FFT analysis valo kaj kore. portable and easy to carry. ami khub satisfy.
