Specification:

Speed

• Max Printing Speed: 1000mm/s
• Max Acceleration: 30000mm/s²
• Max Flow Rate: 90mm³/s @PLA

Body

• Build Volume: Φ260mm×330mm
• Chamber: Closed

Tool Head

• Nozzle: 0.4mm Brass Nozzle
• Max Hot End Temp.: 300°C
• Filament Diameter: 1.75mm

Heated Bed

• Build Plate: Textured PEI Plate
• Max Build Plate Temp.: 110°C

Sensors

• Monitoring Camera: Realtime, Timelapse
• Filament Detection: Yes
• Vibration Compensation: Yes
• Auto-Leveling: Yes
• Power Loss Recovery: Yes

Electronics

• Display: 4.3" Color Touch Screen
• Storage: 8GB EMMC, 16GB USB Flash
• Power Supply: 110-240V, 50/60Hz

Physical Dimension

• Dimension: 436×490×836mm
• Net Weight: 18.41kg

Software

• Slicing Software: FLSUN Slicer, Third-Party Slicer Supported
• Slicer Supported OS: MacOS, Windows
• Formats for Slicing: STL, OBJ, AMF, 3MF
• Supported Filament: PLA, PETG, TPU, PVA, PET, ABS, ASA, PA, PC etc.

Disclaimer:

• The peak speed of tool head is 1000mm/s. The speed is adaptive automatically based on the printing algorithms. The actual speed may differ due to the printing parameter, printing model, slicing software and environment.

• The decibel level is collected by FLSUN laboratory under the condition of enclosed chamber and one-meter away from the printer. The actual decibel level may differ from ambient decibel level, room size and shape, adjacent surface, and atmospheric conditions.

• The max acceleration of tool head refer to the peak instantaneous acceleration. The acceleration is adaptive automatically based on the printing algorithms. The actual acceleration may differ due to the printing parameter, printing model, slicing software and environment.

• The peak flow refer to the instantaneous flow. The flow is adaptive automatically based on the printing algorithms. The actual flow may differ due to the printing parameter, printing model, slicing software and environment.

• The data is collected by FLSUN laboratory under the same environment and same printing parameter.

• The maximum build height refer to the height of center point. The height limit is greatest at the center point, gradually decreases along the cylindrical axis, and is lowest at the edges at 285mm.

Product pictures are for reference only. Please refer to the actual product. Certain product specifications and descriptions may change due to reasons such as changes in suppliers or manufacturers. The data on the page is provided by FLSUN-designed technical parameters, and test data is collected from laboratories and suppliers. In actual circumstances, the data will differ slightly, depending on the test software version, specific testing environment, and specific version.
