DC-DC Converter 10-32V to 35-60V 120W Step Up Boost Adjustable Voltage Charger Power Supply Module is a high-performance non-isolated DC boost converter designed to convert lower DC input voltage into a higher adjustable output voltage. This step-up power supply module supports 10V to 32V input and provides adjustable 35V to 60V output, making it suitable for battery charging, electric vehicle power systems, solar applications, automotive electronics, and DIY adjustable power supply projects.

This high-power boost converter module features adjustable voltage control, high conversion efficiency, metal construction, and compact size. It can be used to convert 12V battery power into higher voltage outputs such as 36V, 48V, and other applications requiring increased DC voltage. The module is suitable for charging batteries with higher voltage ratings, including electric vehicle batteries, when used with proper protection circuits.

Features:

• High-power DC-DC step-up boost converter module

• Converts 10V-32V DC input voltage to adjustable 35V-60V DC output

• Maximum output current up to 5A

• Maximum power up to 120W with enhanced cooling

• Non-isolated boost converter design

• Adjustable output voltage control

• Suitable for battery charging applications

• Metal construction for improved durability

• Compact module size for easy installation

• High conversion efficiency up to approximately 90%

• Low output ripple for stable power delivery

• Suitable for automotive and solar power systems

• Supports DIY adjustable vehicle power supply applications

• Ideal for electric vehicle battery charging projects

• Designed for high-voltage DC conversion applications

Applications:

• Electric vehicle battery charging

• Solar battery charging systems

• Automotive power supply conversion

• 12V battery to 36V/48V power conversion

• DIY adjustable DC power supply

• Battery-powered equipment

• High voltage LED power systems

• Robotics and automation projects

• Industrial DC power applications

• Portable power supply systems

• Electronic testing and development projects

How to Use:

• Connect the DC input power source to the input terminals.

• Adjust the output voltage according to the required application.

• Connect the output terminals to the load or battery charging circuit.

• Use appropriate protection devices such as fuses and reverse polarity protection diodes.

• Ensure proper cooling when operating at high current or maximum power levels.

Battery Charging Application:

• This module can boost a lower voltage DC source to charge higher voltage batteries.

• Example: A 12V power supply can be converted to a higher voltage output for charging a 36V or 48V battery system.

• Proper charging control circuitry should be used according to the battery type.

• Monitor charging voltage and current to prevent battery damage.

Product Instructions:

• This module does not include short circuit protection. Install a fuse or external protection circuit at the input side if required.

• Input reverse polarity protection is not included. Connect a protection diode in series with the input power line.

• Output voltage cannot be lower than the input voltage.

• For input current above 10A, additional cooling is required.

• Ensure sufficient airflow when operating near maximum power.

• Check voltage settings before connecting sensitive devices.

• This is a non-isolated converter, meaning input and output share a common ground.

Specifications:

• Product Type: DC-DC Boost Converter Module

• Converter Type: Step-Up Voltage Converter

• Input Voltage: DC 10V-32V

• Output Voltage: DC 35V-60V Adjustable

• Maximum Input Current: 16A

• Maximum Output Current: 5A

• Maximum Power: 120W (with enhanced cooling)

• Natural Cooling Power: 80W Maximum

• Efficiency: Approximately 90%

• Output Ripple: 2% Maximum (20M bandwidth)

• Load Regulation: ±0.5%

• Voltage Regulation: ±0.5%

• Dynamic Response Speed: 5% / 200μS

• Protection Type: External Protection Required

• Short Circuit Protection: Not Included

• Reverse Polarity Protection: Not Included

• Material: Metal

• Module Size: 65 x 47 x 23.5mm

• Installation Type: PCB Power Module

• Application Type: Battery Charger, Voltage Booster, Power Converter
