The DB9/RS232/RS485 9-Pin Terminal Female Breakout Board is a versatile and reliable solution for connecting serial devices in electronics projects. Designed for RS232 and RS485 communication, this module features a 9-pin female DB9 connector with screw terminals for secure and easy wiring. Ideal for industrial, DIY, and embedded system projects, it simplifies serial communication and provides a robust interface for monitoring, debugging, and data transfer applications in Bangladesh.

Features:

• 9-pin DB9 female connector for RS232 and RS485 serial communication

• Screw terminals allow secure and easy wiring without soldering

• Supports both RS232 and RS485 interfaces for versatile applications

• Compact breakout board design for easy integration into electronic projects

• Clear labeling of each pin for simple connection and wiring

• Durable PCB construction suitable for repeated use

• Ideal for industrial, automation, DIY electronics, and embedded system applications

• Provides a reliable interface for serial communication between devices

• Helps in prototyping, debugging, and data transfer for microcontrollers, PLCs, and serial devices

How to Use

• Connect the DB9 female connector to a corresponding male DB9 port on your device

• Use the screw terminals to attach RS232 or RS485 wires securely

• Verify correct pin connections according to your device’s serial communication requirements

• Connect power or ground if required by the circuit

• Integrate into your electronics project or prototype for monitoring or communication

• Use in combination with microcontrollers, PCs, PLCs, or serial sensors for data transfer

Product Instructions

• Ensure proper RS232 or RS485 wiring to avoid communication errors

• Tighten screw terminals securely to maintain stable connections

• Avoid exceeding the voltage and current limits of the serial interface

• Keep the breakout board in a dry and dust-free environment for optimal performance

• Suitable for repeated connection and disconnection in testing and prototyping environments

Specifications:

• Connector Type: DB9 female

• Interface: RS232 / RS485 serial communication

• Number of Pins: 9

• Pin Connection: Screw terminal

• Board Type: Breakout board for easy prototyping

• Compatibility: PCs, microcontrollers, PLCs, embedded systems, serial devices

• Material: PCB with durable terminal connectors
