DALY SMART BMS 8S 24V 100A wtih Balance for Lithium Iron Phosphate LiFePO4 Battery + Bluetooth
Order before 12.00PM
Product Details / DALY SMART BMS 8S 24V 100A wtih Balance for Lithium Iron Phosphate LiFePO4 Battery + Bluetooth
Daly 8S 100A BMS + Bluetooth
BMS and Balancer Features:
- Charge, Discharge Protection Current, Voltage range are permanently programmed inside BMS and cannot be changed. This is a 8S fixed configuration BMS. It cannot be used for any other battery pack configuration. This BMS also cannot be used for Li-ion, Li-Metal or LTO batteries. It is strictly for LiFePO4 battery packs only.
- Battery Balance function
- Box contains: Rated voltage 24V BMS, balance sense cable (9 Wire sense cable with connector) and instruction sheet.
- Battery pack will stop charging when voltage reaches 3.7V and stop discharging when voltage reaches 2.5V of a cell.
- Temperature range of this BMS is from -20℃ to as high up to 70℃
- It is used for any lithium battery applications including solar, RV, Electric bikes, Skate board, camping, Boat, Power tools, Lawn moving and household energy storage systems
- This version supports bluetooth to program the BMS and monitor battery.
Apps for Android and iPhone are available to download here:
- Charging Protection - Seiko IC effectively controls MOS to prevent battery overcharge and battery explosion
- Discharge Protection - Prevent battery power from dying and affect the life of lithium batteries.
- Over Current Protection - Prevent the battery from being damaged by excessive instantaneous current.
- Short Circuit Protection - Automatic protection during abnormal short circuit to prevent battery.
- Temperature Protection - The NTC temperature control probe is added to prevent the damage caused by the spontaneous combustion of the battery when the temperature is too high.
- Drop Protection - When the cable is taken off, the BMS will provide no output.
