The CNC Linear Motion Guide Slide Table Linear Mechanism is a high-precision linear axis system engineered for CNC machines, automation equipment, and industrial motion control applications. Constructed with heavy-duty aluminum, precision MGN linear rails, and a high-quality ball screw drive system, this linear slide table delivers smooth, accurate, and repeatable linear motion. Equipped with a powerful Nema23 stepper motor, it ensures stable torque output and precise positioning for demanding CNC and automation tasks in Bangladesh.

This custom CNC linear motion guide is available in 500mm and 1000mm travel lengths, making it suitable for a wide range of machine sizes and project requirements. The use of MGN linear guide rails significantly reduces friction and vibration while improving load handling and motion accuracy. The ball screw mechanism minimizes backlash and enhances positioning precision, making this linear slide table ideal for CNC routers, laser machines, milling systems, robotics, and custom industrial automation solutions.

Features:

• Heavy-duty aluminum body for high rigidity and long service life

• Precision MGN linear rail system for smooth and stable motion

• Ball screw drive system for high accuracy and low backlash

• Integrated Nema23 stepper motor for reliable motion control

• Available in 500mm and 1000mm linear travel lengths

• Custom-built CNC linear motion mechanism

• High load-bearing capability and excellent repeatability

• Reduced vibration and noise during operation

• Suitable for continuous-duty industrial and CNC applications

• Easy integration into CNC machines and automation frames

Specifications:

• Product Type: CNC Linear Motion Guide Slide Table

• Body Material: Heavy-duty aluminum

• Linear Rail Type: MGN precision linear guide rail

• Drive System: Ball screw mechanism

• Motor Type: Nema23 stepper motor

• Travel Length Options: 500mm, 1000mm

• Motion Type: Linear sliding motion

• Precision Level: High accuracy and repeatability

• Application Environment: CNC machines, automation, robotics

• Mounting Type: CNC frame surface mount compatible

Applications:

• CNC router and CNC milling machines

• Laser cutting and laser engraving machines

• Industrial automation and linear actuator systems

• Pick and place machines

• Robotics and motion control projects

• CNC plasma and PCB engraving machines

• 3D printer linear axis upgrades

• DIY CNC and custom machine builds

How to Use:

• Securely mount the linear slide table onto a rigid CNC machine frame

• Connect the Nema23 stepper motor to a compatible stepper driver

• Align the MGN linear rails and ball screw accurately

• Configure motor steps, speed, and acceleration in the CNC controller

• Perform calibration and limit testing before operation

• Run the system within recommended load and speed parameters

Installation and Maintenance Instructions:

• Ensure precise alignment during installation to avoid rail wear

• Apply regular lubrication to the ball screw and linear rails

• Keep rails and screw free from dust, debris, and metal particles

• Periodically inspect fasteners, couplings, and motor mounts

• Avoid overloading beyond design limits

• Operate in a clean and controlled environment for best performance

Why Choose This CNC Linear Motion Guide System:

• High-precision motion control using MGN linear rails

• Strong and durable aluminum construction for industrial use

• Ball screw system ensures smooth and accurate linear travel

• Flexible length options for various CNC and automation needs

• Ideal for professional manufacturing and advanced DIY CNC projects
