High Quality RCBO Residual Current Circuit Breaker is a authentic protection device designed to ensure maximum electrical safety in residential, commercial, and industrial low-voltage distribution systems. This compact breaker integrates overload, short-circuit, and earth leakage protection into one unit, making it a reliable and space-saving solution for modern electrical installations. With compliance to IEC/EN 61009-1 standards and CE certification, the RCBO ensures fast and accurate disconnection in case of faults, preventing electric shocks, equipment damage, and fire hazards.

Certifications & Standards:

• IEC/EN 61009-1

• CE Certified

Features:

• Integrated protection against overload, short-circuit, and earth leakage
• Compact design ideal for space-limited distribution boards
• High reliability with fast disconnection during earth faults
• Type A RCBO for AC and pulsating DC leakage current detection
• Visual indicators for ON/OFF and fault status
• Quick and easy DIN rail mounting
• Improves user safety with 30mA leakage current protection

Specifications:

• Model: NXBLE-32 RCBO
• Rated Current (In): 32A
• Residual Operating Current (IΔn): 30mA
• Rated Voltage (Ue): 230V AC, 50/60 Hz
• Poles: 1P+N
• Breaking Capacity: 6000A (6kA)
• Tripping Curve: B curve / C curve
• Residual Current Type: Type A (AC + pulsating DC)
• Mounting: 35mm DIN rail
• Terminal Capacity: Up to 25mm² rigid conductor
• Operating Temperature: -5°C to +40°C
• Protection Degree: IP20 (front face IP40 in enclosure)
• Standards: IEC/EN 61009-1, CE Certified

Applications:

• Residential home electrical safety
• Commercial building power distribution systems
• Industrial control panels and machinery
• Protection for socket outlets and lighting circuits
• Low-voltage electrical distribution requiring leakage protection

NXBLE-32 RCBO Bangladesh, RCBO circuit breaker price in Bangladesh, residual current circuit breaker with overload protection, 32A RCBO 1P+N, Type A RCBO Bangladesh, RCCB with MCB function, DIN rail RCBO, CE certified RCBO breaker, IEC 61009-1 RCBO, electrical safety breaker Bangladesh, 6kA RCBO circuit breaker, short-circuit and earth leakage breaker, low voltage electrical distribution RCBO, industrial RCBO breaker, residential RCBO protection device Bangladesh.

Hiigh quality RCBO residual current circuit breaker that combines overload, short-circuit, and earth leakage protection into a single compact unit. Designed for residential, commercial, and industrial low-voltage distribution systems, the NXBLE-32 ensures enhanced electrical safety by rapidly disconnecting the circuit in case of ground faults, leakage currents, or electrical faults.
