The Bambu Lab AMS HT is an automatic filament feeding, drying, and storage system designed for Bambu Lab 3D printers and a wide range of standard and high-temperature engineering filaments. BDTronics offers the Bambu Lab AMS HT for users who need automatic material feeding, active filament drying up to 85°C, airtight storage, RFID filament identification, and reliable multi-material printing.

BDTronics Bambu Lab AMS HT combines filament drying and automatic material management in one system, helping reduce moisture-related printing problems while keeping filament ready for use. With active moisture discharge, rotating spool drying, airtight storage, humidity monitoring and automatic filament switching, AMS HT is designed for moisture-sensitive materials such as PA, PC, PVA, BVOH and other engineering filaments.

The AMS HT features a brushless servo drive for controlled filament feeding and switching, Filament Odometry for automatic filament length measurement, and RFID identification for compatible Bambu Lab RFID spools. Multiple AMS HT units can be connected within the Bambu Lab ecosystem to support up to 24 colors or materials for compatible multicolor printing setups.

Features:

• Bambu Lab AMS HT Automatic Material System

• Automatic filament feeding system

• Active filament drying up to 85°C

• Designed for standard and engineering-grade 3D printing materials

• Airtight filament storage after drying

• Active moisture discharge

• Rotating Drying Mode for more even spool heating

• Electromagnetic Air Vent for controlled airflow

• Real-time temperature monitoring

• Real-time humidity monitoring

• Real-time drying time display

• Brushless servo drive

• Automatic filament feeding

• Automatic material switching during printing

• Automatic RFID identification for compatible Bambu Lab filament spools

• Filament Odometry for automatic filament length measurement

• Top cover opening detection

• Supports cascading multiple AMS units

• Up to 24 colors or materials with compatible Bambu Lab ecosystem configurations

• Supports 1.75mm filament

• Supports a wide range of PLA, PETG, ABS, ASA, PET, PA, PC, PP, POM, HIPS and other materials

• Dedicated bypass filament outlet for compatible materials

• PC/PA body construction

• UL 94 V-0 fire resistance classification

• 24V DC operating system

• Compact desktop design

Specifications:

• Brand: Bambu Lab

• Model: AMS HT

• Product Type: Automatic Filament Feeding and Drying System

• Filament Diameter: 1.75mm

• Maximum Drying Temperature: 85°C

• Active Moisture Discharge: Supported

• Rotating Spool Drying: Supported

• Airtight Storage: Supported

• Top Cover Opening Detection: Supported

• RFID Identification: Supported

• Filament Odometry: Supported

• Supported Spool Width: 50–68mm

• Supported Spool Diameter: 197–202mm

• Display: Temperature, Humidity and Drying Time

• Body Material: PC/PA

• Fire Resistance: UL 94 V-0

• Operating Voltage: DC 24V

• Input Voltage: AC 100–240V

• Input Frequency: 50/60Hz

• Average Power Consumption: 150W

• Dimensions: 114 × 280 × 245mm

• Weight: 1.21kg

Active Filament Drying:

• AMS HT can actively dry filament at temperatures up to 85°C.

• Suitable for preparing moisture-sensitive materials before printing.

• Rotating spool drying helps expose different sections of the filament spool to the circulating heat.

• Active moisture discharge removes moisture from inside the drying chamber during the drying process.

• Different supported materials can use appropriate drying modes according to their requirements.

• Drying performance depends on filament material, moisture level, ambient humidity, spool condition and drying duration.

Airtight Filament Storage:

• After completing a drying cycle, AMS HT can maintain an airtight storage environment.

• Airtight storage helps reduce moisture reabsorption from surrounding air.

• This is particularly useful for moisture-sensitive materials such as PA, PVA, BVOH and PC.

• Keeping filament enclosed after drying can help maintain its condition before and during printing.

• Desiccant is included to assist with moisture control inside the storage environment.

Temperature and Humidity Monitoring:

• The integrated front display provides real-time information about the filament environment.

• Displays internal temperature.

• Displays humidity level.

• Displays remaining drying time.

• Users can monitor drying progress directly from the AMS HT without requiring additional software for basic status information.

• Continuous monitoring helps users understand the current drying conditions.

Rotating Drying Mode:

• The filament spool rotates during the drying process.

• Rotation helps distribute heat more evenly around the spool.

• More consistent exposure to heated air can improve drying uniformity.

• The system is designed to combine spool rotation, heating and active moisture discharge during drying.

Electromagnetic Air Vent:

• AMS HT uses an electromagnetic air vent as part of its moisture removal system.

• The vent is controlled according to the device's drying operation algorithms.

• Controlled airflow assists active moisture discharge during drying.

• The system can transition to airtight storage after the drying cycle.

Automatic Filament Feeding:

• AMS HT automatically feeds filament to a compatible Bambu Lab printing system.

• The brushless servo drive provides controlled filament movement.

• Automatic feeding reduces the need for manually pushing filament through the material path.

• The system can automatically manage filament switching during supported multicolor printing workflows.

RFID Filament Identification:

• Compatible Bambu Lab RFID filament spools can be automatically recognized.

• RFID identification can provide material information to the connected Bambu Lab ecosystem.

• Automatic recognition reduces manual material configuration for compatible RFID-tagged spools.

• RFID functionality depends on using compatible Bambu Lab RFID filament.

Filament Odometry:

• Filament Odometry provides automatic measurement of filament movement and length.

• It helps the system monitor filament feeding during operation.

• Automatic filament measurement can improve material management and feeding control.

• This feature is particularly useful for automated printing workflows.

Supported Filament Materials:

AMS HT supports a wide range of 1.75mm filaments, including:

• PLA

• PETG

• ABS

• ASA

• PET

• PA

• PC

• PVA when properly dried

• BVOH when properly dried

• PP

• POM

• HIPS

• Bambu PLA-CF

• Bambu PAHT-CF

• Bambu PETG-CF

• Support for PLA

• Support for PETG

• TPU for AMS

Bypass Filament Outlet:

The dedicated bypass filament outlet is designed for compatible materials that should not be routed through the standard AMS feeding mechanism. Supported bypass materials include:

• TPE

• Universal TPU

• Bambu PET-CF

• Bambu TPU 95A

• Other compatible carbon-fiber-filled materials

• Other compatible fiberglass-filled materials

Always verify filament compatibility with the connected Bambu Lab printer and AMS configuration before printing.

Unsupported Materials:

• PVA in wet condition

• BVOH in wet condition

PVA and BVOH should be properly dried before use when supported by the system. Moisture-sensitive filament can absorb significant moisture from ambient air, particularly in humid environments.

Multi-Color and Multi-Material Printing:

• AMS HT integrates with the Bambu Lab automatic material management ecosystem.

• Multiple compatible AMS units can be connected through cascading connections.

• A compatible configuration can support up to 24 colors or materials.

• Automatic material switching can occur according to the requirements of a supported multicolor print.

• This is useful for multicolor models, multi-material prints and automated filament management.

• Actual maximum color/material capacity depends on the complete Bambu Lab printer and AMS configuration.

Spool Compatibility:

• Compatible filament diameter: 1.75mm

• Supported spool width: 50–68mm

• Supported spool diameter: 197–202mm

• Check spool dimensions before inserting filament.

• Ensure the spool can rotate freely inside the AMS HT.

• Filament spool shape and material winding should allow reliable automatic feeding.

• Third-party filament spools should be checked for physical compatibility before use.

Package Contents:

• 1 × Bambu Lab AMS HT

• 2 × Desiccant

• 2 × 263mm PTFE Tubes

• 1 × 900mm PTFE Tube

• 1 × Bambu Bus Cable 6-Pin

• 1 × Power Cable for Bambu AMS HT

Why Use Bambu Lab AMS HT?

• Combines automatic filament feeding and filament drying in one system.

• Reduces the need for a separate filament dryer for compatible materials.

• Helps keep moisture-sensitive filament dry before and during printing.

• Automatic material switching simplifies multicolor printing.

• RFID recognition reduces manual filament identification.

• Filament Odometry provides automated filament movement measurement.

• Airtight storage helps reduce moisture reabsorption.

• High-temperature drying up to 85°C supports a wider range of engineering materials.

• Real-time temperature and humidity information makes filament conditions easier to monitor.

• Suitable for users working with multiple filament materials and colors.

Applications:

• Bambu Lab 3D printers

• Automatic filament feeding

• Automatic filament drying

• Multicolor 3D printing

• Multi-material 3D printing

• Engineering filament drying

• PLA printing

• PETG printing

• ABS printing

• ASA printing

• PA Nylon printing

• PC printing

• PVA printing

• BVOH printing

• Carbon fiber filament printing

• Glass fiber filament printing

• TPU printing

• Moisture-sensitive filament storage

• Professional 3D printing

• High-temperature 3D printing

• Automated 3D printing

• 3D printing farms

• Advanced desktop 3D printing
