The 470uF 100V Radial Electrolytic Capacitor is a high-voltage aluminum electrolytic capacitor designed for DC filtering, voltage smoothing, energy storage and power supply applications. BDTronics offers this 470µF 100V capacitor for use in power supplies, inverters, battery chargers, amplifiers, DC-DC converters and other electronic circuits requiring substantial bulk capacitance.

BDTronics 470uF 100V radial electrolytic capacitor features a 100V DC voltage rating and 470µF capacitance in a large 35×40mm cylindrical package. Its relatively high capacitance makes it useful for reducing low-frequency voltage ripple and providing energy storage on DC power rails.

Features:

• Capacitance: 470µF

• Rated voltage: 100V DC

• Aluminum electrolytic capacitor

• Polarized capacitor

• Radial lead configuration

• Large-capacity bulk filtering

• Suitable for DC voltage smoothing

• Useful for power supply filtering

• Suitable for inverter and charger circuits

• Useful for DC bus filtering

• Suitable for amplifier power supplies

• Compact cylindrical construction for its capacitance and voltage rating

• 35×40mm physical size

• Suitable for through-hole PCB mounting and custom wiring applications

Specifications:

• Capacitor Type: Aluminum Electrolytic

• Capacitance: 470µF

• Rated Voltage: 100V DC

• Polarity: Polarized

• Mounting Type: Radial / Through-Hole

• Package Shape: Cylindrical

• Dimensions: 35mm diameter × 40mm height

• Capacitance Code: 470µF

• Voltage Code: 100V

• Application: Power supply filtering, DC smoothing and energy storage

• Package Size: 35×40mm

Electrical Characteristics:

• 470µF capacitance provides bulk energy storage on DC power rails.

• 100V rated voltage makes it suitable for DC circuits operating below the capacitor's maximum rated voltage.

• As a polarized electrolytic capacitor, positive and negative terminals must be connected correctly.

• Suitable for filtering rectified DC and smoothing voltage variations.

• Actual ripple-current capability, ESR, leakage current and operating temperature depend on the specific manufacturer's series and should be verified from its datasheet where these parameters are critical.

Common Applications:

• SMPS power supplies

• Linear power supplies

• DC power supply filtering

• AC-to-DC rectifier circuits

• Inverter DC bus

• Solar inverter circuits

• Battery charger circuits

• DC-DC converters

• Boost converters

• Buck converters

• Motor controller power supplies

• Audio amplifier power supplies

• Industrial power electronics

• Energy storage circuits

• Voltage smoothing

• Ripple reduction

• DC link filtering

• Electronic repair and replacement

• DIY electronics projects

Use in Power Supply Circuits:

• Connect the capacitor across the DC supply rail where bulk filtering is required.

• Observe correct polarity when installing.

• The positive terminal connects to the positive DC rail and the negative terminal connects to the negative or ground rail.

• In rectifier circuits, the capacitor can be used after the bridge rectifier to smooth pulsating DC.

• In switching power supplies and converters, it can provide bulk capacitance on suitable DC rails.

• Ensure the circuit voltage remains below the capacitor's 100V rated voltage.

• Consider ripple current and ESR requirements when selecting capacitors for high-frequency or high-power applications.

Use in Inverter and Charger Circuits:

• The 470µF 100V capacitor can be used as bulk DC-link capacitance in suitable low-voltage DC bus sections.

• It can help reduce voltage fluctuations caused by switching loads.

• Multiple capacitors can be connected in parallel when additional capacitance is required, provided voltage and ripple-current requirements are properly considered.

• For high-power inverter applications, select capacitors based on required ripple current, ESR, temperature rating and expected operating life rather than capacitance and voltage alone.

Installation Instructions:

• Switch off and completely isolate the circuit before installation.

• Discharge existing capacitors before replacing or installing components.

• Identify the positive and negative terminals.

• Install the capacitor with correct polarity.

• Do not exceed the 100V DC rated voltage.

• Ensure sufficient PCB clearance for the 35mm diameter and 40mm height.

• Verify lead spacing and mechanical clearance before PCB installation.

• After installation, inspect polarity and connections before applying power.

Important Safety Notes:

• This is a polarized electrolytic capacitor.

• Reverse polarity can cause excessive leakage current, heating, venting or capacitor failure.

• Never intentionally operate the capacitor above its rated voltage.

• Always discharge the capacitor before handling a circuit containing it.

• For high-voltage DC applications, allow an appropriate safety margin below the 100V rating.

• When used in high-ripple or high-frequency circuits, verify the capacitor's ripple-current and ESR specifications for the actual application.
