Carbon Fiber 120mm Micro Drone Frame Quadcopter Frame is a lightweight and durable airframe designed for small brushed-motor quadcopters. This frame is optimized for 1020 brushed DC motors (10mm x 20mm) and supports compact flight controllers such as Micro SciSky and SPRacing EVO 32-bit flight controller.

Supplied by BDTronics Bangladesh, this micro drone frame is suitable for DIY FPV builds, indoor drones, training quadcopters, and experimental autopilot projects using Cleanflight. The integrated camera mount allows easy installation of micro FPV cameras, while the ducted frame design improves propeller protection and flight stability. With low overall weight and balanced geometry, this frame is ideal for efficient flight performance using brushed motors.

Features:

• Lightweight Carbon Fiber micro quadcopter frame for brushed motor drones

• Designed for 1020 brushed DC motors (10x20mm)

• Integrated camera mount for micro FPV camera installation

• Ducted frame design for propeller protection and safer flight

• Compatible with Micro SciSky and SPRacing EVO 32-bit flight controller

• Supports Cleanflight autopilot system

• Compact 120mm frame size suitable for indoor flying

• Durable plastic construction for repeated use

• Easy assembly for DIY drone builders

Applications:

• DIY micro quadcopter builds

• Indoor FPV drone projects

• Educational drone training platforms

• Experimental flight controller testing

• Cleanflight-based brushed motor drones

• Lightweight racing or practice drones

How to Use:

• Install 1020 brushed motors securely into motor mounts

• Mount the Micro SciSky or SPRacing EVO flight controller at the center

• Attach the camera using the included camera mount cover

• Connect motors to the flight controller motor outputs

• Configure Cleanflight firmware settings

• Perform basic calibration before flight

• Test hover and stability in a controlled environment

Specifications:

• Material: Plastic

• Weight: Approx. 28g

• Frame Size: 120mm x 120mm

• Supported Motor Type: 1020 brushed DC motor (10mm x 20mm)

• Color: White / Black / Cyan / Blue (random)

Package Includes:

• 1 x 120mm Micro Drone Frame

• 1 x Camera Mount Cover
