AVR ISP Programmable Expansion Shield Board Module

In stock

AVR ISP Programmable Expansion Shield Board Burning Bootloader Programmer Atmega328P Boot Loader Module With Buzzer & LED Indicator For Arduino UNO R3 ...See more
SKU BTS-00002695
SF Code V1.R2
Share:
Tags: Modules Shields
Write Your Own Review
Only registered users can write reviews. Please Sign in or create an account
Details Reviews

Specifications:

  • Compatibility: As it uses SPI pins of ICSP interface, compatible with Arduino R3 / Arduino Mega2560, can change to the bootloader burner when it is directly plugged onto the two boards.
  • Operating voltage: 5V
  • Operating current: 500mA (max)
  • Arduino board to be burned: support Arduino R3 / Mega2560 / Nano / pro mini (5V 16M)
  • On-board buzzer, if the fuse bit is successfully modified, it will sound once, and then if burning bootloader is OK, it will sound once again. If it is not two beeps, burning is failed. You can capture the sound instead of LED lights, so this will improve the efficiency of burning.
  • On-board LED indicators, HEART BEAT led lights up like a breathing light when powered normally. During programming, the PROG indicator flashes until it finishes. If the programming is unsuccessful, the ERROR indicator (red) will light.
  • Onboard 28P locking seat for Atmega328P, Atmega168P, Atmega8 bootloader burning
  • Onboard ISP_6PIN interface, for the external Arduino board bootloader burning
  • On-board ISP_10PIN interface
  • On-board FT232RL and CH340G USB to TTL programmer interface for uploading code to the chip on the 28P locking seat.

Package:

1 X AVR ISP Shield Burning Bootloader
