1.5KW Water Cooled Spindle Motor with VFD, Pump, Aluminium Mount ER11 Collet Sets
In stock
Order before 12.00PM
Product Details / 1.5KW Water Cooled Spindle Motor with VFD, Pump, Aluminium Mount ER11 Collet Sets
Features:
a. CNC Spindle Motor:
- Size:65mm(1.5kw) / 80mm (2.2kw)
- Power:1.5KW / 2.2KW
- Voltage:110V / 220V (Automatically match different countries)
- Frequency:0-400Hz
- Speed:0-24000rpm
- Water Cooling:ER11 /ER20 collet
- Runout off: less than 0.1mm
- Grease Lubrication
- Bearing:4pcs Bearing C7005X2 Â C7002X2
Â
b. Inverter
- Type: 1.5KW-220V
- Input: 110V/220V, AC 50Hz
- Output: 0-220V / 0-110V, AC 3-phase
- Frequency: 0-400Hz
the parameter of the inverter is :
PD005=400
PD004=400
PD003=400
Note:If there is no problem, please do not change the parameters of the inverter.
Â
Variable Frequency Drive VFD Inverter  110V/220VAC:
1) PID control; advanced calculus PID closed-loop arithmetic, quick responding speed and high suitability;
2) Easy PLC function can realize 16 legs of speed and inverter control function;
3) RS485 communication port, adopting standard international MODBUS main circuit control;
4) With extremely strong anti-jamming capability
5) Low output ratting torque0.5HZ-150%, low speed running ability;
6) Carrier adjustable by 16KHZ, completely soundless working environment;
7) Broad voltage working area, normal running in 304V-456V;
8) Auto voltage regulation (AVR) technique, for ensuring the inverter load capability;
9) Various control technique by both synchronization and non-synchronization, dynamically realize fast starting without changing brakes;
10) With perfect error protection and short circuit starting protection capability;
Â
c. Water Pump:
- AC Voltage: 220v-240v/50hz
- Flow: 3500L / h
- Power: 80w
- Qmax:3500L/H
- Structure:single-stage pump
- Pressure :high pressure
Don't operata without water.
Caution: Read the instructions carefully before using !
Â
d. ER20 Collet 1 Set:
Gripping Range: 1MM to 13MM(1,2,3.175,4,5,6,7,8,9,10,11,12.7,13mm)
Â
e. 5M Water Pipes:
Size:5M 6mm (ID)*8mm (OD)
Â
6.Spindle Motor Clamp :
- Diameter: 80mm
- Material: Aluminum,Surface sandblasted
Â
Applications:
Wood working industry rourter, such as wood door milling engraving and cutting, furniture producing
Â
Package Includes:
- 1 x 1.5KW CNC Water Cooled Spindle
- 1 x 1.5KW VFD
- 1 x 3.5M Water Pump
- 1 x 5M Water Pipes
- 1 x 65mm Spindle Clamp
- 13 x ER11 Collets (1mm, 2mm, 3.175mm, 4mm, 5mm, 6mm, 7mm, 8mm, 9mm, 10mm, 11mm,12.7mm,13mm)
